565 Trailer Sprayer - Parts & Schematics
Section F
46
Section F
1 016201 Weldment; Safety Tank Mount, 565 1
2 6000-30Y Tank; 9 Gal. Rinse Tank, Yellow 1
3 0009-UY Tank; 9 Gal. Tank, Molded (Yellow) 1
4 RW01 Rivet Washer, 3/8 OD x 3/16 ID 4
5 000016 Cover, 9 Gal. Tank Molded 1
6 0001-U Lid, 9 Gal. Tank Molded 1
7 0710 Latch, 07-70-201-12 Living BK 1
8 1253 Spigot, Natural 3/4” 1
9 30200 Hinge, Butt H03-30200-171-ZINC 2
10 38-504-08-13 Rivet, Drive 1/8 x .234-.266 2
11 38-504-12-13 Rivet, Drive 1/8 x .359-.391 2
12 400 Rivet, 3/16 x AD64-AH Closed 4
13 600 Rivet, 3/16 x .440 LG Domehead 4
14 A3412 Hose Fitting; 3/4MPT x 1/2” HB 1
15 EL3412 Hose Fitting; 3/4MPT x 1/2” HB 1
16 H Clamp, Speedy Fits 1/2” Hose 1
17 SIGHT-12 Hose, 1/2” ID x 1/8” Wall Sight -
18 BH-031-075-2 Bolt; 5/16 x 3/4 GR 2 4
19 FW-031 Flatwasher; 5/16” 4
20 LW-031 Lockwasher; 5/16” 4
21 BH-038-5-5 Bolt, 3/8” x 5” GR 5 3
22 LN-038-NI Locknut; 3/8” Nylon Insert 3
Item# Part # Description Quantity
Description: 9 Gallon Tank Assembly
