PROGRAMMABLE
HYDRAULIC
We recommend to have oil changed and unit checked by
BAUM and/or authorized personnel.
Attention when bleeding hot oil - danger of burning!
Oil change: approx. every 6000 hrs.
Fill in oil up to middle of oil level indicator!
Quantity (liters): 22,5
GUIDINGS FOR KNIFE AND CLAMP (grease lubrication)
Lubrication by grease gun!
1. Move backgauge to position 42 cm (16,5 inches)!
2. Remove lid (C) at backgauge drive guard
3. Grease spindle via lubricating nipple
2 - 3 strokes with the grease gun are sufficient.
Lubrication intervals: monthly
Lubrication by grease gun!
1. Lubricate guidings for knife bar (A) from the front side:
2 lubricating nipples at the front plate
2. Lubricate clamp guidings from the rear side (B):
2 lubricating nipples
2 - 3 strokes with the grease gun are sufficient.
Lubrication intervals: weekly
BACKGAUGE DRIVE (grease lubrication)
ARAL Vitam GF 46
AGIP Oso 46
BP Energol HLP-HM 46
CASTROL Hyspin SP 46
DEA Astron HLP 46
ESSO Nuto H 46
ELF Elfolna 46
FINA Hydran AF 46
FUCHS Renolin B, rot
KLÜBER Lamora HLP 46
MOBIL DTE 25
OPTIMOL Hydo 46 or Hydo MV 32
SHELL Tellus C 46
TOTAL Azolla ZS 467
Usable grease brands (DIN 51825, in alphabetical order):
ARAL Radlagerfett
AGIP Autol Top 2000 or
Longtime Grease 2
BP Energrease LS 2
DEA Paragon EP 2
ESSO Unirex N2 or Essonorva 275
FINA Pluton AX 2
KLÜBER Centoplex 2 EP
MOBIL Mobilgrease XHP 222
OPTIMOL Longtime PD 2
SHELL Retinax LX 2
TOTAL Multis EP 2
A
B
C
Usable oil brands (DIN 51524, in alphabetical order):
