K5B - 1
1 2
3
4 5
6
7 8 9
C
0
x
D
i
PROGRAMMABLE
5.0 Automatic Operation
Machine Functions and Additional Functions (Menu Keys)
Machine Functions
Machine functions are basic functions of the machine. They can be changed for
the program sequence.
The machine functions can be selected by pressing one of the following push-
buttons:
• Main Menu (Function Survey) (page K5B - 2)
• Auxiliary Functions (page K5D - 1)
• Machine Parameters (page K5E - 1)
Additional Functions
The running of cutting programs can be further automated by using additional
functions.
For this purpose, a multi-function key is available to the user.
• Additional Functions (page K5C - 1)
After any of the menu keys has been pressed a survey menu is opened which
offers several functions.
The corresponding subfunctions of the menu keys are selected by choosing the
respective identification number of the pictograph (symbol) and can be transfer-
red into the currently selected program.
A special function stored will be indicated in the Program Data display as a
pictograph (symbol) behind the cut size.
It is possible to store several additional functions into one step number.
Operating panel with menu keys:
Additional Functions
Main Menu
(Function Survey)
Auxiliary Functions
Machine Parameters
