K1 - 10
• Observe the procedures described in case of malfunctions and the mainte
nance intervals indicated.
Residual Risk
In spite of the safety measures provided by construction there remains a
residual risk when operating the machine.
This residual risk mainly concerns the danger of contusions and cuts during
clamping, cutting or knife change as well as handling the cutting material in
general, if the necessary care is neglected.
The parts especially affected are the upper extremities of the operating staff -
especially their arms and hands.
Special care must be taken when performing the knife change. It may only be
carried out by personnel especially trained for this job!
During knife change no other persons must enter the working area of the
machine (cuts)!
Permissible Environmental and Operating Conditions
Operate the machine in closed areas, exclusively!
Air humidity: 35% - 95% (non condensing)
Ambient air temperature: +5°C - +40°C
Hydraulic Data
Hydraulic pressure, max.: 160 bars!
Safety Precautions
• Minimum age of operating staff: 18 years!
• Before starting any work at the machine - read safety section of manual!
• During the working process no other persons must enter the working area or
interfere with the process
• Use the angle included in the scope of supply for positioning the cutting
material
• Knife change may only be carried out by personnel especially trained for this
purpose
• Utmost care must be taken when handling the knife!! Always deposit or
transport the knife in the knife case.
• Use only undamaged and sharp knives!
• During the cutting no tool or objects - such as e.g. T-wrench must be on the
machine table in order to prevent them from reaching unintentionally under
the clamp and/or knife during the cutting process. There is a high risk of
injuries due to little parts of the knife edge coming off in splinters.
1.0 Technical Data/Machine Layout/Transport and Installation of Machine/Safety Relevant Machine Elements
Technical Data
