K5A - 4
Contin.: Basic Display: Program Data
5.0 Automatic Operation
Conc. 5 Display of Additional functions
Display of the pictograph/s representing the Additional function/s
Conc. 6 Status display "Actual machine function"
Display of the pictograph representing the actual machine function
Conc. 7 Display section "Additional function"
Indication of the additional function to be stored after function has
been selected from menu.
Conc. 8 Pictographs user prompting
Indication of possible operating functions in the current menu
Conc. 9 Actual programming function with pictograph
Indication of current programming function as a plain text and as
a pictograph
Conc. 10 Scroll bar
For paging through the actual menu image; movement by cursor
keys
Conc. 1 Program Head shows:
P: Program number of indicated program with memory segment
e.g. 1A = program 1, memory segment A and program
protection (asterisk)
S: Quantity of step numbers assigned by the program
Conc. 2 Program Data section shows:
e.g. 1 step number of program (with abbrev. for parti-
cular additional functions such as Eltrotact
etc.)
Pictograph(s) additional function(s) stored:
Display of pictograph/s (symbol(s) of additional
function(s) stored
Conc. 3 Input section shows:
Data (cut size)/arithmetic functions entered
Conc. 4 "Position display“ section shows:
ACTUAL POSITION Actual backgauge position/measuring unit
NOMINAL POSITION Indication of nominal position
