131
Specifications
Appendix B. Product Specifications
This appendix contains storage system enclosure and module specifications.
Table 31. Enclosure Specifications
Weight:
Deskside Net, Min. Config.
1
:
14 kg (31 lb)
Deskside Net, Max. Config.
2
:
25 kg (55 lb)
Deskside Shipping, Min. Config.
1
:
18 kg (40 lb)
Deskside Shipping, Max. Config.
2
:
30 kg (66 lb)
Rackmount Net, Min. Config.
1
:
16 kg (35 lb)
Rackmount Net, Max. Config.
2
:
28 kg (62 lb)
Rackmount Shipping, Min. Config.
1
:
22 kg (49 lb)
Rackmount Shipping, Max. Config.
2
:
34 kg (75 lb)
Dimensions:
Deskside Enclosure: 415 mm H x 310 mm W x 320 mm D (16.34 in x 12.2 in x 12.6 in)
Rackmount Enclosure: 263 mm H x 425 mm W x 265 mm D (10.35 in x 16.73 in x 10.43 in)
Deskside Packaging: 673 mm H x 406 mm W x 432 mm D (26.5 in x 15.98 in x 17.01 in)
Rackmount Packaging: 584 mm H x 508 mm W x 610 mm D (23 in x 20 in x 24.02 in)
Line Input Requirements:
Input Power
3
:
400 W (120 Vac @ 3.3 A; 230 Vac @ 1.7 A)
Nominal Voltages: 100/120/127 Vac, 8 A max; 200/230 Vac, 4 A max
Inclusive Voltage Range: 88-140 Vac; 180-269 Vac
Nominal Frequencies: 60 Hz (120 Vac), 50 Hz (230 Vac)
Inclusive Frequency Range: 47.5 to 66 Hz
Fast Rise:
1 kV, 1 µsec duration, 1 pulse/cycle for 10 min
Surge Transient:
1 kV, 50 µsec duration, 1 pulse/cycle every 10 sec
Ringing Wave: 3 kV, 100 kHz
Brownout: 88/180 to 0 Vac over 30 min
Brownout Recovery: 0 to 88/180 Vac over 30 min
Transparent Line Surge: 293 Vac for 500 msec
Recoverable Line Surge: 298 Vac for 500 msec
Line Voltage Sag: 80.5 Vac for 500 msec
Line Dropout:
≤ 20 msec
Notes:
1. Minimum Configuration is 2 fan modules, 1 power module, no disk modules
2. Maximum Configuration is 2 fan modules, 2 power modules, eight 1-inch disk modules
3. Worst case during spin-up; Maximum Configuration
