Installation & Configuration
Installing Additional Modules
10
Installation
Installing Additional Modules
CAUTION! Do not touch the rear connector on a module. The module is susceptible to
electrostatic discharge (ESD) and damage to components may occur.
CAUTION! Do not install a single-ended (SE) module into a differential (DF) bus or a DF
module into an SE bus. The SCSI bus will hang and damage to the host bus adapter
(HBA) may occur.
NOTE! You should install storage modules in the order from bottom to top and from left to right.
The storage system is shipped with two fan modules and one power module. An additional power module,
disk modules, and DDS tape modules can be installed. Figure 5 shows the storage systems with their 1-
inch slot reference designators. 1-inch disk modules can use any of the 1-inch slots in bay A (A1 through
A4) and bay B (B1 through B4). 1.6-inch disk modules and DDS tape modules use two 1-inch slots. 1-
inch and 1.6-inch modules can be installed in a storage system in any combination of slots in bay A and
bay B.
