YORK INTERNATIONAL
FORM 160.81-EG1
FLA =
Motor kW
x Max. Motor FLA
Max. Motor kW
The benefit from the FLA correction is the possible use
of smaller power wiring and/or starter size.
The locked rotor amperes (LRA) are read directly from
Tables 3 and 4 for specific Motor Code and voltage. This
is because the LRA is dependent only on motor size and
voltage and is independent of input power (kW).
Inrush amperes (IRA) depend on LRA and the type of
starter applied. The inrush can be calculated using a
percentage of LRA shown in Table 5.
TABLE 3 – 60 HZ ELECTRICAL DATA
NAME-
AMP
MOTOR DATA
COMP. PLATE
(MAX)
100% 90% 80% 70% 60% 50% 40% 30% 20% MAX.
VOLT.
FLA LRA PF EFF PF EFF PF EFF PF EFF PF EFF PF EFF PF EFF PF EFF PF EFF KW (hp)
200 850 3634 88.2 94.8 87.8 95.2 87.3 95.5 85.8 95.7 84.3 95.9 80.4 96.0 76.5 96.0 65.8 95.2 55.1 94.4
208 825 3779 86.6 95.0 85.6 95.3 84.6 95.5 82.6 95.7 80.5 95.9 75.5 95.8 70.5 95.7 59.0 94.8 47.4 93.8
230 725 2901 89.2 94.5 89.1 95.0 89.0 95.4 88.2 95.7 87.3 96.0 84.5 96.1 81.6 96.2 72.4 95.6 63.1 94.9
240 695 3027 88.2 94.9 87.7 95.2 87.2 95.5 85.8 95.8 84.3 96.0 80.4 96.0 76.5 96.0 65.8 95.2 55.0 94.4
T0/T1 380 438 1727 89.3 94.6 89.3 95.0 89.2 95.4 88.5 95.7 87.8 96.0 85.1 96.1 82.4 96.2 73.5 95.6 64.6 95.0 251.6
440 370 1390 89.6 94.2 89.8 94.7 90.0 95.2 89.6 95.6 89.2 95.9 87.2 96.1 85.2 96.3 77.7 95.9 70.1 95.4 (321)
460 354 1453 89.2 94.6 89.1 95.0 88.9 95.4 88.1 95.7 87.3 96.0 84.5 96.1 81.6 96.2 72.4 95.6 63.1 94.9
480 339 1516 88.2 94.9 87.7 95.2 87.2 95.5 85.8 95.8 84.3 96.0 80.4 96.0 76.5 96.0 65.8 95.2 55.0 94.4
575 300 1162 89.2 94.6 89.1 95.0 88.9 95.4 88.1 95.7 87.3 96.0 84.4 96.1 81.5 96.2 72.3 95.6 93.1 95.0
600 288 1213 88.2 94.9 87.7 95.3 87.2 95.6 85.8 95.8 84.3 96.0 80.4 96.0 76.5 96.0 65.8 95.3 55.0 94.5
200 882 4048 90.4 94.8 90.2 95.2 90.0 95.5 89.2 95.8 88.3 96.0 85.6 96.0 82.9 96.0 73.8 95.3 64.7 94.6
208 860 4210 89.1 95.0 88.5 95.3 87.8 95.6 86.4 95.8 94.9 96.0 81.3 96.0 77.6 95.9 67.1 95.0 56.5 94.1
230 760 3520 90.5 94.7 90.4 95.1 90.2 95.4 89.5 95.7 88.7 95.9 86.2 96.0 83.7 96.0 75.0 95.4 66.3 94.7
240 737 3673 89.3 95.0 88.8 95.3 88.3 95.5 86.9 95.7 85.4 95.9 81.9 95.9 78.3 95.9 67.9 95.0 57.5 94.1
T2/T3 380 464 2130 90.3 94.8 90.1 95.2 89.9 95.5 89.1 95.8 88.2 96.0 85.6 96.0 82.9 96.0 73.8 95.3 64.7 94.6 275.9
440 400 1603 91.0 94.4 91.2 94.9 91.4 95.3 91.1 95.6 90.8 95.9 89.3 96.1 87.7 96.2 80.9 95.7 74.0 95.1 (351)
460 383 1676 90.5 94.7 90.4 95.1 90.2 95.5 89.5 95.8 88.7 96.0 86.2 96.1 83.7 96.1 75.0 95.4 66.2 94.7
480 372 1749 89.3 95.0 88.8 95.3 88.2 95.6 86.8 95.8 85.4 96.0 81.8 96.0 78.2 95.9 67.9 95.0 57.5 94.1
575 305 1408 90.7 94.7 90.7 95.1 90.6 95.5 90.0 95.8 89.4 96.0 87.2 96.1 85.0 96.2 77.0 95.5 68.9 94.8
600 293 1469 89.9 95.0 89.5 95.3 89.1 95.6 88.0 95.8 86.9 96.0 83.8 96.0 80.7 96.0 71.0 95.2 61.2 94.4
NOTE: FLA = Full-load Amps; LRA = Locked Rotor Amps; PF = Power Factor; EFF = Motor Efficiency
100% Loading is Percentage of Maximum Motor Load; not of Specific Application
