26
YORK INTERNATIONAL
FORM 160.81-EG1
TOP VIEW
8-1/2"
(216 mm)
M
RELIEF VALVES
(SEE TABLE)
J
A
K
2' - 3-1/2"
(698 mm)
2' - 6-1/4"
(768 mm)
3'-8-3/4 "
(1136.7 mm)
OIL SEPARATOR
SOLID STATE STARTER
(OPTIONAL)
OPTIVIEW
CONTROL PANEL
L
F
C
D
E
G
B
SECTION A - A
CONDENSER
EVAPORATOR
RELIEF VALVE
NOTE: ONLY SUPPLIED
ON UNITS WITH
OPTIONAL ISOLATION
VALVES
ISOLATION VALVE
NOTE: OPTIONAL
H
RELIEF VALVE
(SEE TABLE)
ISOLATION VALVE
NOTE: OPTIONAL
FRONT OF UNIT
MOTOR
COMPRESSOR
MOTOR
END
COMPRESSOR
END
MOTOR
END
COMPRESSOR
END
B
C
U
P
Dimensions
LD07981
FIG. 3 – T0 & T3 COMPRESSORS – EVAPORATOR, CONDENSER AND WATER BOXES DIMENSIONS
RELIEF VALVES*
LOCATION
WITH ISOLATION WITHOUT ISOLATION
VALVES VALVES
EVAPORATOR 1" SINGLE 1" DUAL
CONDENSER 1" DUAL 1" SINGLE
DISCHARGE
1-1/4" SINGLE NONE
LINE
*All are NPT female
