Appendix 3.1 Restriction for Packing
175
Appendix 3.1.1 Target Products
The following Mitsubishi NC products use lithium batteries. If the lithium metal content exceeds 1g for battery cell and 2g for
battery, the battery is classified as dangerous good (Class9).
In order to avoid an accidental actuation during the transportation, all lithium battery products incorporated in a machinery or
device must be fixed securely and must be shipped with wrapped over the outer package as to prevent damage or short-
circuits.
(1) Materials falling under Class 9
(2) Materials not falling under Class 9
(Note) If the number of batteries exceeds 24 batteries for the battery cell or 12 batteries for the battery, the dedicated
packing (for materials falling under Class 9) is required.
(Example) Rating nameplate for battery units
Mitsubishi type
(Type for arrangement)
Battery type
Lithium metal
content
Number of
incorporated
ER6V batteries
Application
(Data backup)
Battery
class
Outline dimension
drawing
CR23500SE-CJ5 CR23500SE-CJ5 1.52g -
For NC SRAM
(M500)
Battery
cell
Refer to "Battery Option" in
the specification manual
for drive unit you are using
for the outline dimension
drawing for servo.
Mitsubishi type
(Type for arrangement)
Battery type
Lithium metal
content
Number of
incorporated
ER6V batteries
Application
(Data backup)
Battery
class
Outline dimension
drawing
CR2032
(for built-in battery)
CR2032 0.067g - For NC SRAM/
Battery
cell
Refer to "Battery Option" in
the specification manual
for drive unit you are using
for the outline dimension
drawing for servo.
CR2450
(for built-in battery)
CR2450 0.173g - For NC SRAM
ER6, ER6V series
(for built-in battery)
ER6, ER6V 0.65g -
For NC SRAM/
servo detector
A6BAT(MR-BAT) ER17330V 0.48g - For servo detector
Q6BAT Q6BAT 0.49g - For NC SRAM
Lithium metal content
Safety class
Battery manufacturer type
Mitsubishi type
