Turbomachinery Package Specification Taurus 60 Compressor Set and Mechanical Drive
4.2.7 Hydrostatic Testing
Hydrostatic pressure testing of all compressor casings and end caps is done per API 617
for 30 minutes at 1.5 times the maximum casing design pressure, regardless of
application. Test water is treated with a wetting agent to allow better penetration of
possible casing defects. After the hydro and final magnetic particle test, the casing is
steam cleaned and bead blasted for surface preparation. Afterwards, it is painted per
Solar’s specification ES 9-58.
4.2.8 Shaft Coupling
Solar’s standard shaft interconnect is a Kop-Flex dry coupling.
4.2.9 Preliminary Alignment
The drive train is aligned preliminarily at the factory to simplify final field alignment.
Table 4. Driven Equipment and Associated Equipment Specifications
Typical Driven Skid Weight
One to Three Compressor Bodies 6800 to 34 000 kg (15,000 to 75,000 lb)
Typical Driven Skid Lengths
One to Three Compressor Bodies 4.0 to 10 m (13 to 33 ft)
Compressor Inspection Interval
Major Inspection Interval Three Years of Continuous Full-Load Duty
Compressor Construction Materials
Impeller 15-5PH, Type 100
Casing ASTM A216 GR WCC
Diaphragm/Guide Vane Alloy Steel
Rotor Spacer Alloy Steel
Stub Shafts AISI 4140
Labyrinth Steel-Backed Babbitt
Compressor Bearings
Journal Bearing Tilting Pad
Thrust Bearing Self Aligning, Tilting Pad
Compressor Vibration Monitoring
Driver End Bearing Displacement Probes, X and Y Axis
Driven End Bearing Displacement Probes, X and Y Axis
Thrust Bearing Displacement Probe, Axial
Compressor Rotor Shaft Keyphasor
Seal Gas
Fluid Clean Process Gas or Nitrogen
Particle Size Less Than 2 micron
Minimum Supply Pressure
689 kPag (100 psig) above highest compressor
suction pressure but below pressure rating of
seal system
Maximum Supply Pressure 13 790 kPag (2000 psig)
Flow 1.3 to 3.3 nm
3
/min (50 to 125 SCFM)
Temperature 0 to 93°C (32 to 200°F)
Separation Gas
Air Quality
Refer to Solar Engineering Specification ES
2201
Supply Pressure 517 to 1344 kPag (75 to 195 psig)
Flow 0.134 nm
3
/min (5 SCFM)
Solar’s Applicable Engineering Specifications
ES 9-58 Standard Paint Program - Turbomachinery
© 2009 Solar Turbines Incorporated. All rights reserved. TPS60CSMD/309
17
