Turbomachinery Package Specification Taurus 60 Compressor Set and Mechanical Drive
Table 1. Package Specifications
Dimensions
Approximate Package Measurements
Height, Unenclosed 2.72 m (8 ft 11 in.)
Height, Enclosed 3.20 m (10 ft 6 in.)
Width (to skid edges) 2.46 m (8 ft 1 in.)
Width (including lifting bollards) 2.59 m (8 ft 6 in.)
Length, Engine Skid 6.02 m (19 ft 9 in.)
Approximate Package Weights
AC Start Motor Assembly 370 kg (820 lb)
Pneumatic Start Assembly 260 kg (570 lb)
Gas Turbine Assembly (SoLoNOx) 3290 kg (7250 lb)
Total Driver (unenclosed package, without oil) 15 422 kg (34,000 lb)
Total Driver (enclosed package, with oil) 20 607 kg (45,430 lb)
Piping and Tubing Thickness
Piping > 76.2 mm (3 in.) Nominal Pipe Size (NPS) Schedule 40 (Unless Otherwise Specified)
Piping < 50.8 mm (2 in.) NPS Schedule 80 (Unless Otherwise Specified)
Tubing 3.175 mm (0.125 in.) Nominal Tubing Size
(NTS)
0.889 mm (0.035 in.) Minimum Wall Thickness
Tubing 6.35 mm (0.25 in.) NTS 1.245 mm (0.049 in.) Minimum Wall Thickness
Tubing 12.7 mm (0.500 in.) NTS 1.651 mm (0.065 in.) Minimum Wall Thickness
Tubing 19.05 mm (0.75 in.) NTS 1.651 mm (0.065 in.) Minimum Wall Thickness
Tubing 25.40 mm (1.00 in.) NTS 2.108 mm (0.083 in.) Minimum Wall Thickness
Tubing 31.75 mm (1.25 in.) NTS 2.768 mm (0.109 in.) Minimum Wall Thickness
Construction Materials
Piping, Manifolds, and Tubing < 10.2 cm (4 in.)
Note (a)
316L Stainless Steel (Unless Otherwise Specified)
Piping, Manifolds, and Tubing > 10.2 cm (4 in.)
Note (a)
Carbon Steel (Unless Otherwise Specified)
Piping Interface Connections 316L Stainless Steel (Unless Otherwise Specified)
Flange Assembly Hardware 316L Stainless Steel
Pipe Support Brackets
Carbon Steel (Standard)
316L Stainless Steel (Optional)
Pipe Flexible Couplings
Carbon Steel (Standard)
316L Stainless Steel (Optional)
Tubing Dual Ferrule Compression Fittings 316L Stainless Steel
Sliding Lube Oil Drain Couplings and Plates
Carbon Steel (Standard)
316L Stainless Steel (Optional)
Lube Oil Vent Flame Arrestor
Carbon Steel (Standard)
316L Stainless Steel (Optional)
Electrical System Certifications
NEC Class 1, Group D, Division 1 or 2
CENELEC Zone 1 or 2, Group II
CE, ATEX Zone 2, Group II
Three-Phase Package Motors
Optional Motor Voltage Ratings
380, 400, or 415 VAC, 50 Hz
460 VAC 60 Hz
Single-Phase Battery Charger
Optional Battery Charger Voltage Ratings
220, 230, 240, 380, 400, 415, 440, 460, or 480
VAC, 50 Hz or 60 Hz
© 2009 Solar Turbines Incorporated. All rights reserved. TPS60CSMD/309
8
