Turbomachinery Package Specification Taurus 60 Compressor Set and Mechanical Drive
Construction Materials
Prefilter/Barrier
Carbon Steel (Standard); 316L Stainless Steel
(Optional)
Insect Screen (Optional) 316L Stainless Steel
Self Cleaning Barriers
Carbon Steel (Standard); 316L Stainless Steel
(Optional)
Marine High Velocity Air Cleaner 316L Stainless Steel
Offshore / Coastal Medium Velocity Type Air
Filter
316L Stainless Steel (Standard), Carbon Steel
(Optional for mild coastal environments)
Air Inlet Silencer
Carbon Steel (Standard); 316L Stainless Steel
(Optional)
Air Inlet Support Structure Carbon Steel (Standard)
Solar’s Applicable Product Information Letters
PIL 054 OSHA Noise Requirements
PIL 178 Salt Ingress Protection for Gas Turbines
Notes:
(a) The particle size in the compressed air stream should not exceed 10μm. Since it is
impractical to remove 100% of all particles larger than 10μm, this is defined as ß10 > 100, or
99% efficient. Oil or hydrocarbon content should not exceed 1 ppm. The dew point at line
pressure shall be at least 6°C (10°F) below the minimum temperature to which any part of
the air system is exposed or between 1.6°C and 60°C (35°F and 140°F). Air should be free
of all corrosive contaminants, hazardous gases, flammables, and toxics.
© 2009 Solar Turbines Incorporated. All rights reserved. TPS60CSMD/309
