Turbomachinery Package Specification Taurus 60 Compressor Set and Mechanical Drive
9.1.7 Lube Oil Vent Flame Arrestor
The lube oil vent flame arrestor prevents an ignition source from entering the lube oil
tank. The flame arrestor is loose shipped for offskid installation by others.
9.1.8 Lube Oil System Options
Lube Oil Cooler
An air-to-oil type cooler is available to provide oil cooling for the gas turbine and the
driven equipment. The cooler is sized for specified heat loads and ambient temperatures
and is designed for a 22.2°C (40°F) approach temperature. The cooler is loose shipped
for offskid installation by others.
Lube Oil Immersion Tank Heater
The lube oil tank immersion heater ensures the lube oil tank temperature is adequate for
starting in cold conditions. The tank heater also facilitates a short lube oil temperature
warm up period after a cold start. Electrical supply contactors are not included.
Table 9. Lubrication System Specifications
Main Lube Oil Pump
Pump Type Engine-Driven Rotary Screw
Flow 1060 lpm (280 gpm)
Discharge Pressure
607 kPag (88 psig), See Note (a)
Pre/Post Lube Oil Pump
Pump Type AC Motor-Driven Centrifugal
Optional Motor Voltage Ratings
380 VAC, 400 VAC, and 415 VAC (50 Hz)
460 VAC and 575 VAC (60 Hz)
Motor, Power 7.5 kW (10 hp)
Backup Lube Oil Pump
Pump Type DC Motor-Driven Centrifugal
Motor Voltage Rating 110 VDC
Motor, Power 0.9 kW (1.2 hp)
Lube Oil Cooler
Lube Cooler Oil Volume (Per Cooler) Project Specific
Design Heat Load (Per Cooler) Project Specific
Design Oil Flow Rate (Per Cooler) Project Specific
Air Flow Rate
Project Specific, See Note (b)
Maximum Ambient Temperature 43°C (110°F)
Maximum Design Lube Oil Cooler Outlet
Temperature
66°C (150°F)
Maximum Lube Oil Cooler Design Pressure Drop
173 kPag (25 psig), See Note (c)
Minimum Lube Oil Cooler Design Pressure 1 035 kPag (150 psig)
Optional Motor Voltage Ratings
380 VAC, 400 VAC, and 415 VAC (50 Hz)
460 VAC and 575 AC (60 Hz)
Optional Motor, Power 7.5 kW (10 hp), 15 kW (20 hp), or 2 x 15 kW (20 hp)
Lube Oil Tank Immersion Heater, See Note (d) and (e)
Optional Voltage Ratings
380 VAC, 400 VAC, and 415 VAC (50 Hz)
460 VAC (60 Hz)
Power 3-Phase VAC, 10 kW
Minimum/Maximum Regulated Supply Pressure 100 to 225 psig (689 to 1551 kPag)
Maximum Flow Demand Rate 4.67 nm
3
/min. (165 scfm)
