Combination Square Must Be True - Checking Combination Square
1. Position square and
draw a light line
2. Flip square (shown in dotted position)
3. Check edge of flipped square against
the drawn line. There should be no gap
or overlap at the bottom end.
drawn line
3/4" board with
straight top edge
no gap or overlap
Tools Needed for Assembly and Alignment
Combination Square
6/4mm Hex Key
(supplied)
10mm Socket
(supplied)
#2 Phillips Screwdriver
NOTE: A 6mm and a 4mm hex key can be
substituted for the supplied 6/4mm hex key.
