54
GE Multilin
35 F1 Last Trip Ambient RTD Class 1 Note 3
36 F4 Last Trip Hottest Ambient RTD
Temperature (°C)
Class 1 Note 3
37 F12 Pre-Trip Analog Input 1 Class 1 Notes 3,9
38 F12 Pre-Trip Analog Input 2 Class 1 Notes 3,9
39 F12 Pre-Trip Analog Input 3 Class 1 Notes 3,9
40 F12 Pre-Trip Analog Input 4 Class 1 Notes 3,9
41 F1 Pre-Trip Fundamental Frequency Neutral
Voltage (volts)
Class 1 Notes 3,10
42 F10 Pre-Trip Fundamental Frequency Neutral
Voltage (tenths of a volt)
Class 1 Notes 3,10
43 F1 Pre-Trip Third Harmonic Neutral Voltage
(volts)
Class 1 Notes 3,10
44 F10 Pre-Trip Third Harmonic Neutral Voltage
(tenths of a volt)
Class 1 Notes 3,10
45 F2 Pre-Trip Vab/Iab (loss of excitation
impedance)
Class 1 Note 3
46 F1 Pre-Trip Vab/Iab Angle (loss of excitation
impedance angle)
Class 1 Note 3
47 F1 Scale factor for current readings (points
marked with “Note 7”). Will always be a
power of 10 (1, 10, 100, etc.). Changes
only when the configuration setpoints are
changed.
Class 1 Note 3
48 F1 Phase A Output Current Class 2 Note 7
49 F1 Phase B Output Current Class 2 Note 7
50 F1 Phase C Output Current Class 2 Note 7
51 F1 Phase A Neutral-Side Current Class 2 Note 7
52 F1 Phase B Neutral-Side Current Class 2 Note 7
53 F1 Phase C Neutral-Side Current Class 2 Note 7
54 F1 Phase A Differential Current Class 2 Note 7
55 F1 Phase B Differential Current Class 2 Note 7
56 F1 Phase C Differential Current Class 2 Note 7
57 F1 Average Phase Current Class 2 Note 7
58 F1 Generator Load (percent) Class 2
59 F1 Negative Sequence Current Class 2
60 F1 Ground Current Scale Factor. Will always
be a power of 10 (1, 10, 100, etc.).
Changes only when the configuration
setpoints are changed.
Class 1 Note 3
61 F3 Ground Current (scaled according to the
previous point)
Class 2
62 F1 Phase A-B Voltage Class 2
63 F1 Phase B-C Voltage Class 2
64 F1 Phase C-A Voltage Class 2
65 F1 Average Line Voltage Class 2
66 F1 Phase A-N Voltage Class 2
67 F1 Phase B-N Voltage Class 2
68 F1 Phase C-N Voltage Class 2
69 F1 Average Phase Voltage Class 2
70 F3 Per Unit Measurement Of V/Hz Class 2
71 F3 Frequency Class 2 Note 2
72 F1 Fundamental Frequency Neutral Voltage
(volts)
Class 2 Note 10
73 F10 Fundamental Frequency Neutral Voltage
(tenths of a volt)
Class 2 Note 10
Table 8: Analog Inputs Point List (Sheet 2 of 4)
INDEX FOR-
MAT
DESCRIPTION EVENT CLASS
ASSIGNED TO
NOTES
