E70 Series Connection Manual
Appendix 1.2 CNP2E-1 Cable
119
Appendix 1.2 CNP2E-1 Cable
Max. cable length: 30m
Application: Motor side PLG cable
Spindle side accuracy detector
TS5690 cable
<Cable connection diagram (for 15m or less)>
<Cable connection diagram (for 15m to 30m)>
1
2
5
6
7
8
3
4
PE
7
8
2
1
5
6
3
4
9
P5(+5V)
LG
MT1
MT2
SD
SD*
RQ
RQ*
P5(+5V)
LG
MT1
MT2
SD
SD*
RQ
RQ*
SHD
0.5mm
2
0.2mm
2
0.2mm
2
0.2mm
2
Spindle drive unit side connector
(3M)
Receptacle: 36210-0100PL
Shell kit: 36310-3200-008
(MOLEX)
Connector set: 54599-1019
Case
grounding
(Note) For the pin "7" or "8", use the contact "170364-1".
For the other pins, use the contact "170363-1".
(Note)
Spindle motor side connector
Connector: 172169-1
Contact: 170363-1(AWG26-22)
170364-1(AWG22-18)
(Tyco Electronics)
1
2
5
6
7
8
3
4
PE
7
8
2
1
5
6
3
4
9
P5(+5V)
LG
MT1
MT2
SD
SD*
RQ
RQ*
P5(+5V)
LG
MT1
MT2
SD
SD*
RQ
RQ*
SHD
0.5mm
2
0.2mm
2
0.2mm
2
0.2mm
2
0.5mm
2
Spindle drive unit side connector
(3M)
Receptacle: 36210-0100PL
Shell kit: 36310-3200-008
(MOLEX)
Connector set: 54599-1019
Case
grounding
(Note) For the pin "7" or "8", use the contact "170364-1".
For the other pins, use the contact "170363-1".
(Note)
Spindle motor side connector
Connector: 172169-1
Contact: 170363-1(AWG26-22)
170364-1(AWG22-18)
Tyco Electronics)
