E70 Series Connection Manual
2.5 Operation Panel I/O Unit
27
[FCU7-DX721/ FCU7-DX731]
(Note) (9) is not available for FCU7-DX731.
(Note) Use M3x25 screws (with spring washer and plain washer) when mounting the operation panel I/O unit.
<Dimension drawing for installing on the panel> <Installation on the back side of the keyboard>
Operation panel I/O unit can be installed on the back side
of the keyboard.
(4)
(5)
(1)
(10)
110 (
(2)
(7)
(8)
(11)
(12)
(3)
(6)
(9)
116
179
(13)
Space required for wiring)
116 ( )
106 ± 0.3
4-M3
179 ( )
171 ± 0.3
Unit outline
Screw
Unit outline
NCKB
Connector
Fixing screw (4 pcs.)
M3x25
(with plain washer and spring washer)
