7.5 Main fuses for SF1-8
Frequency Voltage SF1
single-
phase
SF2
single-
phase
SF2
3-phase
SF4
3-phase
SF6
3-phase
SF8
3-phase
IEC
50 Hz 230 V 20 A 20 A 20 A 20 A 2x 20 A 2x 20 A
50 Hz 400 V 20 A 20 A 2x 20 A 2x 20 A
60 Hz 380 V 20 A 20 A 2x 20 A 2x 20 A
50 Hz 500 V 20 A 20 A 2x 20 A 2x 20 A
CSA/UL
60 Hz 230 V 25 A 25 A 20 A 30 A 20 A 2x 30 A
60 Hz 440/460 V 15 A 15 A 15 A 2x 15 A
7.6 Main fuses for SF6-15 Multi
Frequency Voltage SF6
3-phase
SF8
3-phase
SF11
3-phase
SF15
3-phase
IEC
50 Hz 230 V 32 A 50 A 63 A 80 A
50 Hz 400 V 25 A 32 A 50 A 50 A
60 Hz 380 V 25 A 32 A 50 A 50 A
50 Hz 500 V 20 A 25 A 32 A 50 A
CSA/UL
60 Hz 230 V 45 A 60 A 80 A 110 A
60 Hz 440/460 V 25 A 30 A 45 A 60 A
60 Hz 575 V 20 A 25 A 35 A 45 A
7.7 Reference conditions/limitations
Reference conditions:
Air inlet pressure (absolute) 1 bar
Air inlet temperature 20 °C
Relative air humidity 0%
Nominal working pressure See values below
Limitations
Max. working pressure See values below
Max. ambient temperature 40 °C
Min. ambient temperature 0 °C
