-34-
Ventilation openings and switch levers must be kept
clean and free of foreign matter. Do not attempt to
clean by inserting pointed objects through openings.
Check regularly to make sure the lower guard and
all moving parts are working properly.
Remove accumulated sawdust from working parts
by blowing with compressed air or wiping with a
damp cloth.
2?A.6;092.;6;4.42;A@.;1@<9
C2;A@ 1.:.42 =9.@A60 =.?A@
&<:2<3A52@2.?24.@<96;20.?/<;A2A?.059<
?612059<?6;.A21092.;6;4@<9C2;A@.::<;6.
.;15<B@25<9112A2?42;A@A5.A0<;A.6;.::<
;6.
.?2<39.12@
Blades become dull even from cutting regular lum-
ber. If you find yourself forcing the saw forward to
cut instead of just guiding it through the cut, chances
are the blade is dull or coated with wood pitch.
When cleaning gum and wood pitch from blade, un-
plug the saw and remove the blade. Remember,
blades are designed to cut, so handle carefully. Wipe
the blade with kerosene or similar solvent to remove
the gum and pitch. Unless you are experienced in
sharpening blades, we recommend you do not try.
'<<9 B/?60.A6<;
Your Bosch tool has been properly lubricated and is
ready to use. It is recommended that tools with
gears be regreased with a special gear lubricant at
every brush change.
Periodically lubricate moving parts with a silicone, or
light oil spray. Do not use grease because it tends
to attract and hold sawdust.
2.?6;4@
All bearings in this tools are lubricated with a suffi-
cient amount of high grade lubricant for the life of the
unit under normal operating conditions. No further
lubrication is required.
!.6;A2;.;02.;1 B/?60.A6<;
?B@5
?B@5
'2?:6;.9
FIG. 48
?B@5
.=
!
CAUTION
