Section 6
Specifications & Product Data
Specifications & Product Data 6–1MN735
General Specifications:
Enclosure: Open Type (Protected Chassis)
Enclosure rating: Europe
North America / Canada
IP20
Chassis/IP20
Mounting method: Panel mount or DIN rail mounting (35mm).
Enclosure emissions: Enclosure provides 15dB attenuation to radiated
emissions between 30–100MHz. It must also
require a security tool for opening.
Horsepower: 1/3–2 HP @ 230VAC, 1 Phase
3–5 HP @ 230VAC, 3 Phase
1/2–10 HP @ 460VAC, 3 Phase
Voltage Range: 230 VAC Models
460 VAC Models
198-264 VAC 1φ 60 Hz / 198-264 VAC 1φ 50 Hz
198-264 VAC 3φ 60 Hz / 198-264 VAC 3φ 50 Hz
342-506 VAC 3φ 60 Hz / 342-506 VAC 3φ 50 Hz
Input Line Impedance: 1%
Service Factor: 1.0
Duty: Continuous
Ambient Operating Temperature: 0 to +40 °C with linear derating to 50 °C
(maximum).
Cooling: Forced air included when required.
Rated Storage Temperature: – 25 °C to +55 °C
Humidity: 10 to 85% RH @ 40 °C Non-Condensing
Altitude: Sea level to 3300 Feet (1000 Meters)
Derate 1% per 330 Feet (100 Meters) above 3300
Feet
Shock: 1G
Vibration: 0.5G at 10Hz to 60Hz
Climatic conditions: Class 3k3, as defined by EN50178 (1998)
Safety: Europe
North America / Canada
Overvoltage Category
Pollution Degree
EN50178 (1998), when installed inside suitable
enclosure.
UL508C
Category III (3 phase power), Category II (1 phase
Logic power)
Pollution Degree 2
EMC Compliance: Immunity:
Radiated Emissions:
EN50082–1 (1992), EN50082–2 (1992),
EN61800–3
EN50081–1(1992) and EN61800–3 when mounted
inside the specified enclosure. Control and motor
cables must be screened and correctly installed
with shielded couplings where they exit the
enclosure. Control 0V must be connected to
protective earth/ground.
Conducted Emissions: EN50081–1(1992), EN61800–3 unrestricted
distribution, maximum motor cable length is 25m.
