26
Chapter 2 Installation and Setup
2-1 Checking the Included Items
The following items are included with the machine. Make sure they are all present and accounted for.
Retaining
screw
Spring
Noes-unit retainer
Roland Engrave Studio
CD-ROM
*1: This is for diameter-4.36 mm character or flat cutters. It cannot be used with diamond scrapers or end mills.
*2: Never use a diameter-4.36 mm cutter at a spindle speed of 15,000 rpm or higher. There is danger of damage to the
spindle unit due to vibration.
Power cord
Software guide
(Roland Software Package)
(Roland Engrave Studio)
Depth regulator nose
(nose unit)
Spare tool retaining screw
Character cutter
(diameter 3.175 mm,
with cutter holder)
Flat cutter
(diameter 3.175 mm,
with cutter holder)
Wrench
Collet
(diameter 3.175 mm)
Collet
(diameter 4.36 mm)*1,*2
Hexagonal screwdriver
Hexagonal wrench
Handy panel
Adhesive sheet Vacuum-adapter set User’s Manual
Roland Software Package
CD-ROM
