5 – 4
5.2 Setting Special Functions A
Turn on the cutting plotter while holding down the key. The menus for setting the special functions are
displayed.
Scroll up or down to select the required menu using the (NEXT) or (PREV.) key.
Select the setting details using the or key, and press the (ENTER) key to register the setting. To
cancel the selection, press the (NEXT) or (PREV.) key. The next menu is displayed.
Once all the settings have been made, turn off the cutting plotter.
If the media or home sensors have been disabled (set to DISABLED), be sure to specify
the cutting/plotting area (see “4.11 Setting the Cutting/Plotting Area”). If the cutting/plot-
ting area is not specified, the cutting mat may be damaged.
Step
1
Step
2
Step
3
Step
4
CAUTION
":", ";" ENABLED
"W" PEN DOWN
PRIORITY MANUAL
INIT.B 2mm
UP MODE DISABLED
MEDIA ENABLED
HOME ENABLED
B.W.S. DISABLED
In GP-GL command mode
MODEL 7550
PRIORITY MANUAL
INIT.B 2mm
UP MODE DISABLED
MEDIA ENABLED
HOME ENABLED
CIRCLE AUTO
B.W.S. DISABLED
PAUSE KEY MENU
COPY MENU STD
PAUSE KEY MENU
COPY MENU STD
In HP-GL command mode
