4.22 Setting the PEN UP SPEED
This function sets the travel speed of the pen when it is raised. It can be specified independently of the cut-
ting SPEED function. When the PEN UP SPEED is high, the pen travels faster when it is raised, thereby
reducing the overall cutting time. Your cutting plotter comes with its PEN UP SPEED set to AUTO, which
selects the same speed as the cutting SPEED function (pen lowered). Note that if long-axis cutting of a
medium is performed with a high PEN UP SPEED setting, the medium is susceptible to jamming.
Press the (PAUSE) key to switch to PAUSE mode.
Press the (NEXT) or (PREV.) key until the following menu is displayed.
Press the (ENTER) key to display the pen-up-speed menu.
Use the or key to select the value to be set, and then press the
(ENTER) key to confirm.
Tempo 600: “AUTO” “10” “20” “30” “60” cm/s
To cancel the selection, press the (NEXT) or (PREV.) key.
Press the (PAUSE) key to cancel PAUSE mode.
