2 – 15
While pushing the pen holder in the upward direction, push the pen all the way into the holder until its
flange contacts the upper part of the holder. Make sure that the pen bracket is engaged on the pen’s
flange.
When the cutter pen has been mounted, tighten the screw to hold it in place.
Step
2
When you push the pen holder up with your fingers, take care not to cut your fingers on
the cutter blade.
Step
3
Flange
Pen bracket
CAUTION
Flange
Pen bracket
