3 – 13

Load the medium for test cutting on the cutting plotter.

Use the , , , and (POSITION) keys to move the pen carriage to the position for test cutting.

Switch to READY mode, and then press the (TEST) key.

When test cutting has been completed, the pen carriage moves to the standby position and the following

menu is displayed.

Press the (ENTER) key to return the pen carriage to its previous position and to switch the cutting plot-

ter to READY mode.

Adjust the CUTTER OFFSET value to suit the type and thickness of the medium being used, and ﬁne-

adjust the ﬁnish of each corner. Set the FORCE so that only faint cutting lines remain on the base sheet

when the blade length is properly adjusted.

Upon completion of ﬁne adjustment, actual cutting data can be sent to the cutting plotter.

Step

1

Step

2

Step

3

Step

4

Step

5

Step

6

Step

7

PRESS ENTER KEY

CUTTER

OFFSET

is too low

Increase

(by +1 to +5)

Correct

CUTTER

OFFSET

setting

CUTTER

OFFSET

is too high

Decrease

(by -1 to -5)
