6-12 Replacing the Lamp Technobeam
®
User Manual
(5) Hot lamp may be an explosion hazard. Do
not open for 5 minutes after switching off.
Wear eye and hand protection when re-
lamping.
(6) Never look directly at the lamp while lamp is
on.
(7) Disconnect power before re-lamping or
servicing.
1. Unplug the fixture from the power source.
2. Fully back out the two lamp assembly screws shown in Figure 6-13.
Figure 6-13. Loosening the lamp assembly screws gives you access to the
fixture lamp.
3.
Put on your eye and hand protection.
Pull the lamp assembly straight
out of the back of the fixture as shown in Figure 6-14.
Figure 6-14. Removing the lamp assembly from the fixture.
