A-16 DMX Protocols Technobeam
®
User Manual
Fixture Number to DMX Start Channel
Table A-5 below shows the conversion between fixture number and DMX start
channel. You must understand and use this information if you choose to
control Technobeam using fixture numbering.
* - A link with more than 32 fixtures requires a serial data distributor to
regenerate and retime the signal.
Table A-5. Fixture Number to DMX Start Channel Conversion
Fixture Number
DMX Start Channel
18-ch. (TB F, TB I)
DMX Start Channel
14-ch. (TB R)
11 1
219 15
337 29
455 43
573 57
691 71
7 109 85
8 127 99
9145 113
10 163 127
11 181 141
12 199 155
13 217 169
14 235 183
15 253 197
16 271 211
17 289 225
18 307 239
19 325 253
20 343 267
21 361 281
22 379 295
23 397 309
24 415 323
25 433 337
26 451 351
27 469 365
28 487 379
29
393
30
407
31
421
32
435
33*
449
34*
463
35*
477
36*
491
