Centered on position 10 176 69 B0h
Centered on position 11 196 77 C4h
Centered on position 12 215 84 D7h
Centered on position 13 235 92 EBh
75
Litho wheel functions
Fast litho changes (at beginning
of wheel movement)
Select the function with this
channel. Then use chs. 8, 9 &
10 (F) or chs. 6 & 7 (R) to set
other options.
Random and scan pause time
set by chs. 9 & 10 (F) or ch. 7
(R)
Indexed (wheel snaps
to center of aperture)
0 - 15 0 - 5 00h - 0Fh
Forward spin 16 - 31 6 - 12 10h - 1Fh
Reverse spin 32 - 47 13 - 18 20h - 2Fh
Scan 48 - 63 19 - 24 30h - 3Fh
Blink (same as index,
except shutter closes
between apertures)
64 - 79 25 - 30 40h - 4Fh
Random 80 - 95 31 - 37 50h - 5Fh
Reserved 96 - 111 38 - 43 60h - 6Fh
Wheel spin 112 - 127 44 - 49 70h - 7Fh
Litho changes set by MSpeed
(use ch. 16 (F) or 13 (R) to set
MSpeed time)
Select the parameter with this
channel. Then use chs. 8, 9 &
10 (F) or chs. 6 & 7 (R) to set
other options.
Random and scan pause time
set by ch. 9 (F) or ch. 7 (R)
Indexed (wheel snaps
to center of aperture)
128 - 143 50 - 56 80h - 8Fh
Forward spin 144 - 159 57 - 62 90h - 9Fh
Reverse spin 160 - 175 63 - 68 A0h - AFh
Scan 176 - 191 69 - 74 B0h - BFh
Blink (same as index,
except shutter closes
between apertures)
192 - 207 75 - 81 C0h - CFh
Random 208 - 223 82 - 87 D0h - DFh
Reserved 224 - 239 88 - 93 E0h - EFh
Wheel spin 240 - 255 94 - 100 F0h - FFh
86
Litho wheel position
Position (aperture) selection for
blink or index mode (use with
ch. 5 (F) or 3 (R))
Position 1 (open) 0 - 15
240 - 255
0 - 5
94 - 100
00h - 0Fh
F0h - FFh
Position 2 16 - 47 6 - 18 10h - 2Fh
Position 3 48 - 79 19 - 30 30h - 4Fh
Position 4 80 - 111 31 - 43 50h - 6Fh
Position 5 112 - 143 44 - 56 70h - 8Fh
Position 6 144 - 175 57 - 68 90h - AFh
Position 7 176 - 207 69 - 81 B0h - CFh
Position 8 208 - 239 82 - 93 D0h - EFh
97
Litho rotation (coarse
adjustment) and functions
Angular position for
blink and index modes
0 - 255 0 - 100 00h - FFh
Table A-1. Technobeam DMX Protocol
Ch. (F) Ch. (R) Construct Parameter
Value
(dec.)
Value
(%)
Value
(hex)
