Technobeam
®
User Manual Menu Map 3-7
PRST EDIT
SN01-
SN16
COL
R000 -
R255
select a reverse color wheel spin speed from
none (R000) to fast (R255) (only available if
you selected a COLC construct value of RSP
or MRSP)
D000 -
D358
select a color wheel position in degrees from 0°
(D000) to 358° (D358) (only available if you
selected a COLC construct value of CON or
MCON)
SC 1 -
SC26
slow scan of selected full color base position
(SC 1 - SC13) or half color base position
(SC14 - SC26) (only available if you selected a
COLC construct value of SSC or MSSC)
FC 1 -
FC26
fast scan of selected full color base position
(FC 1 - FC 13) or half color base position
(FC14 - FC26) (only available if you selected a
COLC construct value of FC or MFC)
N000 -
N255
select a pause time between random color
wheel position changes, short (N000) to long
(N255) (only available if you selected a COLC
construct value of RND or MRND)
B 1 -
B 13
shutter blink on selected full color position (only
available if you selected a COLC construct
value of BLK or MBLK)
HB 1 -
HB13
shutter blink on selected half color position
(only available if you selected a COLC
construct value of BLK or MBLK)
LTOC
IDX
litho wheel indexed position (wheel snaps to
center of litho), full speed
FSP litho forward spin, full speed
RSP litho reverse spin, full speed
SC litho wheel scanning, full speed
BLK litho wheel blink selection, full speed
RND litho wheel random color positions, full speed
WSP litho wheel spin, full speed
MIDX litho wheel indexed position, MSpeed
MFSP litho forward spin, MSpeed
MRSP litho reverse spin, MSpeed
M SC litho wheel scanning, MSpeed
MBLK
litho wheel blink selection (wheel snaps to
center of litho and the shutter closes between
positions), MSpeed
MRND litho wheel random color positions, MSpeed
MWSP litho wheel spin, MSpeed
LTO
L 1 -
L 8
select a litho wheel position (only available if
you selected a LTOC construct value of IDX or
MIDX)
LF 1 -
LF 8
select a forward spinning litho position (only
available if you selected a LTOC construct
value of FSP or MFSP)
Table 3-1. Technobeam Menu Map
Menu
Level 1
Menu
Level 2
Menu
Level 3
Menu
Level 4
Menu
Level 5
Description
