User Manual DMX Protocols A-11
10 Iris Close 0 0 00
Variable Iris 1-127 1-50 01-7F
Open 128-135 51-53 80-87
Periodic Strobe 136-151 54-59 88-97
Random Strobe 152-167 60-66 98-A7
Ramp Open/Snap Shut 168-183 67-72 A8-B7
Snap Open/Ramp Shut 184-199 73-78 B8-C7
Ramp Open/Ramp Shut 200-215 79-84 C8-D7
Random Ramp Open/Snap Shut 216-231 85-91 D8-E7
Random Snap Open/Ramp Shut 232-247 92-97 E8-F7
Open 248-255 98-100 F8-FF
11 Effects Wheel
Position
Full Speed Control
Effect 1 0-25 0-10 00-19
Effect 2 26-51 11-20 1A-33
Effect 3 52-76 21-30 34-4C
Effect 4 77-102 31-40 4D-66
Effect 5 103-127 41-50 67-7F
MSpeed Control
Effect 1 128-153 51-60 80-99
Effect 2 154-178 61-70 9A-B2
Effect 3 179-204 71-80 B3-CC
Effect 4 205-229 81-90 CD-E5
Effect 5 230-255 91-100 E6-FF
12 Effects Rotate Rotate Clockwise Fastest 0 0 00
Rotate Clockwise Slowest 120 47 78
No rotation 121-134 48-52 79-86
Rotate Counter-Clockwise Slowest 135 53 87
Rotate Counter-Clockwise Fastest 255 100 FF
13 Focus Focus In 0 0 00
Focus Out 255 100 FF
14 Shutter Close 0-7 0-3 00-07
Periodic Strobe 8-67 4-26 08-43
Random Strobe 68-127 27-50 44-7F
Ramp Open, Snap Shut 128-187 51-73 80-BB
Snap Open, Ramp Shut 188-247 74-97 BC-F7
Open 248-255 98-100 F8-FF
15 Dim Close 0 0 00
Continuously Variable 1-254 1-99 01-FE
Open 255 100 FF
16 MSpeed See Table A-3 on page A-13 for MSpeed times
17 Macro/LAD™ LAD Off 0-7 0-3 00-07
Macro 1 8-11 3-4 08-0B
Macro 2 12-15 5-6 0C-0F
Macro 3 16-19 6-8 10-13
Macro 4 20-23 8-9 14-17
Macro 5 24-27 9-11 18-1B
Macro 6 28-31 11-12 1C-1F
Macro 7 32-35 13-14 20-23
Macro 8 36-39 14-15 24-27
Table A-2. Technobeam-i DMX Protocol
Ch. Construct Parameter
Value
(dec.)
Value
(%)
Value
(hex)
