WIRING CONNECTION TABLES
21.1 Selecting the Right Controller 107
21.2 Wiring Connection Tables for Spray ECU Controllers 109
21.3 Spray ECU (with tails) 111
21.3.1 A1999 (Hagie) Connection Tables 112
21.3.2 A2006 (Raven) Connection Tables 114
21.4 Spray ECU 116
21.4.1 A2036 Spray ECU Connection Tables (060001-060014) 117
21.4.2 A2036 Spray ECU Connection Tables (060015- 060053) 120
21.5 Spray ECU (Raven) 123
21.5.1 A2445 KEE Spray ECU 3 Connection Tables (()50001- 050011) 124
21.5.2 A2445 KEE Spray ECU 3 Connection Tables (060001 -060037) 128
21.6 Spray 10SR 132
21.6.1 Spray ECU 10SR Wiring Connection Tables (060000-060040) 133
21.6.2 Spray ECU 10SR Wiring Connection Tables (060041- ) 137
21.7 Spray ECU 30S 141
21.7.1 Spray ECU 30S Wiring Connection Tables 142
21.8 Hardi 5500 Spray ECU 145
21.8.1 Hardi 5500 Spray ECU Connection Tables 146
21.9 KEE Sprayrate Interface 148
21.9.1 KEE Sprayrate Interface Wiring Connection Tables 149
WIRING SCHEMATICS OF KEE SPRAY ECU TRACTOR AND SPRAYER LOOMS 151-164
SERVICE BULLETINS
23.0 Pressure Relief Valve installation to Raven Fast Flow Valves 166
Contents
Page 5
V1.98 21/06/06
