How to use this Manual
Page 7
V1.98 21/06/06
HOW
TO
USE
THIS
MANUAL
All operators who have a Spray ECU installed must read the following page:
Section 1.0 ‘For all Installations and Servicing of Spray ECU’s’.
UUppggrraaddiinngg
tthhee
ZZYYNNXX
SSpprraayy
RRaattee
CCoonnttrrooll
SSooffttwwaarree
If the ‘Spray Rate Interface’ or ‘Spray ECU’ is already installed and you are using this book to
upgrade the ZYNX Sprayrate Control software to a later version, then go to straight to Section
3.0 ‘Configuration Setup’.
IInnssttaallllaattiioonn
ooff
tthhee
SSpprraayy
EECCUU
1. Read Section 1.0 ‘For all Installations and Servicing of Spray ECU’s’ before attempting
any installations
2. Section 1.1 has details about installing the Spray ECU controller, Power/Comms harness
and KEE Sprayer Switchbox.
3. Then select one of the following installations, depending on which Spray ECU kit
was purchased:
3a. Section 1.2: Installing a complete KEE Spray ECU 30S kit. This section explains how to
install the following: Tractor harness, Sprayer Harness, Valve Harness, wheel sensor kit,
flow sensor kit, connect to a regulating valve, electronic pressure sensor and connect to
a dump valve.
3b. Section 1.3: Installing a Spray ECU 30S kit to an existing KEE MK5 Spray controller or
KEE Spray Rate Interface.
3c. Section 1.4: Installing the 10SR Spray ECU to existing Raven 4xx, 6xx, 4400 and 4600
series controllers. The Spray ECU 10SR has been pinned to allow direct replacement of
some of the Raven 4xx, 6xx, 4400 and 4600 series controllers.
4. This section connects the Spray ECU to the battery. The hardware installation is
complete.
5. Once the Installation is complete then go to Section 2.0 ‘Getting Started’. Go to Section
2.1 if starting an X15 Console
OORR
to Section 2.2 if starting starting an X20 Console.
These sections explain starting the ZYNX Console. The manual from Section 2.3 onward
will be the same whether an X15/X10 Console or X20 Console is used. Section 2.3 checks
the spraying software is registered. This section gives an overview of the Sprayer
Working Screen and how to ‘Navigate Around the Screen’ during setting up the sprayer
software.
6. Section 3.0: ‘Configuration Setup’ explains how to load your KEE Spray kit or Sprayer
from the factory configurations files loaded on the ZYNX Console, if your sprayer is
listed. These configuration files contain most of the sprayer settings required to set up
your sprayer. If your sprayer is listed in the Factory Configurations then you can choose
to do the Quick Setup (Section 3.4)
OORR
manually follow the manual through all the
sprayer software setup options (Section 4 to 15) in the Software Setup Section.
7. (Section 4 through to 15): The Sprayer Software Setup section takes the operator
through the 11 pages of the OPTIONS window to setup the sprayer.
