xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide
795
Parameters
<name 16> - Specify the name of the IP multicast VLAN replication entry to be configured.
add - Specify to add an IP multicast replication entry.
delete - Specify to delete an IP multicast replication entry.
vlan - Specify the outgoing VLAN name.
<vlan_name 32> - The VLAN name can be up to 32 characters long.
vlanid - Specify the outgoing VLAN ID.
<vidlist> - Specify the outgoing VLAN ID here.
ports
- Specify the outgoing port list.
<portlist> - Specify a range of ports to be configured.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure the destination of an IP multicast VLAN replication entry named mr1:
DGS-3420-28SC:admin#config ipmc_vlan_replication_entry destination mr1 add
vlanid 1 ports 10-17
Command: config ipmc_vlan_replication_entry destination mr1 add vlanid 1 ports
10-17
Success.
DGS-3420-28SC:admin#
84-4 config ipmc_vlan_replication_entry source
Description
This command is used to configure the traffic to be replicated by the IP multicast VLAN replication
entry. The traffic is described as a source VLAN, a list of multicast group addresses, and an
optional source IP address associated with the multicast group. Each (V, G, S) will consume one
resource entry. Therefore, the resource entry consumed by a replication entry is not constant and
it will be determined by the number of (V, G, S) pairs defined by the entry. If the entry (V, G, S)
exists in two replication entries, both will take effect. The traffic will be replicated to the destination
defined by both entries.
Format
config ipmc_vlan_replication_entry source <name 16> [[vlan <vlan_name 32> | vlanid
<vlanid 1-4094>] | group [add | delete] mcast_ip <mcast_address_list> {source_ip <ipaddr>}]
Parameters
<name 16> - Specify the name of the IP multicast VLAN replication entry to be configured. This
name can be up to 16 characters long.
vlan - Specify the source VLAN name.
<vlan_name 32> - The VLAN name can be up to 32 characters long.
vlanid - Specify the source VLAN ID.
<vlanid 1-4094> - The VLAN ID must be between 1 and 4094.
group - Specify the multicast IP address list.
