4-2
Cisco 12000/10700 v3.1.1 Router Manager User Guide
OL-4455-01
Chapter 4 Managing Chassis
Launching the Chassis Management Windows
Launching the Chassis Management Windows
Table 4-1 displays the Cisco 12000/10720 Router Manager Chassis Management windows that can be
launched from each object type. For example, the Management Information window can be launched
from a Site, or Chassis object, but cannot be launched from a Module or an Interface object.
Note Table 4-1 lists the menu options to launch the chassis management dialogs from the site level.
Table 4-1 Launching the Chassis Management Windows
Cisco 12000/10720 Router
Manager Window/Task
Objects (that can be selected) to Open the
Window
Menu Options to Select to Open Window
Site Chassis
12000
Series
Chassis
10720
Module Interface
Management
Information
Yes Yes Yes No No Cisco 12000/10720 Manager>Configuration>
Chassis> Management Information
Chassis Configuration Yes Yes Yes No No Cisco 12000/10720 Manager>Configuration>
Chassis>Configuration
SNMP Management Yes Yes Yes No No Cisco 12000/10720 Manager>Configuration>
Chassis>SNMP Management
Chassis Inventory Yes Yes Yes No No Cisco 12000/10720 Manager>Accounting>
Chassis>Inventory
Chassis Fault
Management
Yes Yes Yes No No Cisco 12000/10720 Manager>Fault>Chassis>
Fault Management
Command Log Yes Yes Yes No No Cisco 12000/10720 Manager>Accounting>
Chassis>View>Command Log
System Log Yes Yes Yes No No Cisco 12000/10720 Manager>Fault>
Chassis>SysLog Messages
APS Status Yes Yes Yes No No Cisco 12000/10720 Manager>Fault>Chassis>
POS APS Status
RPR Configuration Yes Yes No No No Cisco 12000/10720 Manager>Configuration>
Chassis>RPR Configuration
RPR Status Yes Yes No No No Cisco 12000/10720 Manager>Fault>Chassis>
RPR Status
IP Routing Status Yes Yes Yes No No Cisco 12000/10720 Manager>Fault>Chassis>IP
Routing Status
TCP Status Yes Yes Yes No No Cisco 12000/10720 Manager>Fault>Chassis>
TCP Status
UDP Status Yes Yes Yes No No Cisco 12000/10720 Manager>Fault>Chassis>
UDP Status
The dialogs mentioned below are launched from the chassis level.
Launching the Web
Console
No Yes Yes Yes Yes Technology Specific Tools>Launch Web Console
