Cisco 12000/10700 v3.1.1 Router Manager User Guide
OL-4455-01
Chapter 14 Routing
BGP Configuration
Redistribution Tab—Detailed Description
The Redistribution tab displays a single area, BGP Redistribution Information
BGP Redistribution Information
Protocol—This displays the protocol whose routes are redistributed by BGP. The redistribute
configuration causes the corresponding routes to be redistributed into BGP.
AS/Tag—A Process ID of the redistributed protocol
IS-IS Routing Level—Routing level of ISIS Protocol
Redistribution Metric—Specifies the metric used for redistributed routes.
Actions
Add/Remove Redistribute—Clicking the Add/Remove Redistribute action button opens the BGP
Redistribute Configuration window. For more details, see “BGP Redistribute Configuration” section on
page 16.
BGP Redistribute Configuration
The BGP Redistribute Configuration window allows the user to add or remove a redistribution entries
from the device. To configure the BGP Redistribute protocol, proceed as follows:
Step 1 Open the BGP configuration window. See “Viewing the BGP Details Tab on the BGP Configuration
Window” section on page 14-3 for further details. Click on the Redistribution tab.
Step 2 Choose the chassis, for which you want to configure the BGP Redistribute, from the left side of the
window.
Note You can choose multiple chassis (from the chassis list) which allows you to launch the BGP
Redistribute Configuration window for the selected chassis.
Step 3 Click on the Add/Remove Redistribute button. The BGP Redistribute Configuration window appears.
