Chapter 15 MPLS Management
Launching the MPLS Management Windows
Launching the MPLS Management Windows
Table 15-1 displays the MPLS Management windows that can be launched from various object types.
For example, the MPLS Forwarding Information window can be launched from a Site, or Chassis object,
but cannot be launched from a Module or an Interface object.
Note Table 15-1 lists the menu options to launch the MPLS Management dialogs from the site level.
Note The Cisco 12000/10720 Router Manager MPLS Management windows cannot be opened when multiple
objects are selected (the menu options to open the windows are grayed out). Available menu options can
be launched from a site object containing the required objects.
Table 15-1 Launching the MPLS Management Windows
Cisco 12000/10720
Router Manager
Window/Task
Objects (that can be selected) to Open the Window
Menu Options to Select to Open Window
Site Chassis Module Interface VRF
12000
Series
10720
MPLS Forwarding
Information
Yes Yes Yes No No No Cisco 12000/10720 Manager> Fault> Chassis>
MPLS> MPLS Forwarding Information
MPLS Interface Status Yes Yes Yes Yes Yes No Cisco 12000/10720 Manager> Fault>
Interface> MPLS> Status
MPLS Interface
Information
Yes Yes Yes No No No Cisco 12000/10720 Manager> Fault> Chassis>
MPLS> MPLS Interface Information
MPLS Interface
Performance
Yes Yes Yes Yes Yes No Cisco 12000/10720 Manager> Performance>
Interface> MPLS> Performance
MPLS LDP Entity
Status Window
Yes Yes Yes No No No Cisco 12000/10720 Manager> Fault> Chassis>
MPLS> MPLS LDP Entity Status
MPLS LDP Hello
Adjacencies
Yes Yes Yes No No No Cisco 12000/10720 Manager> Fault> Chassis>
MPLS> MPLS LDP Hello Adjacencies
MPLS LDP Peer Status Yes Yes Yes No No No Cisco 12000/10720 Manager> Fault> Chassis>
MPLS> MPLS LDP Peer Status
MPLS Tunnel
Information
Yes Yes Yes No No No Cisco 12000/10720 Manager> Fault> Chassis>
MPLS> MPLS Tunnel Information
