8-6
Cisco 12000/10700 v3.1.1 Router Manager User Guide
OL-4455-01
Chapter 8 Interface Configuration
ATM Interface Configuration
Administration Status—Allows you to enable or disable the interface.
Link Up/Down Trap Enable—Allows you to choose whether link up/down traps should be generated for
this interface.
Supplementary Information—Any additional information.
Actions
The Actions area allows you to commission or decommission a selected interface.
Commission—Click Commission to commission the selected interface.
Decommission—Click Decommission to decommission the selected interface.
ATM Interface Configuration
The ATM Interface Configuration window allows you to configure a selected ATM interface. The ATM
Interface Configuration section covers the following areas:
• Viewing the ATM Interface Configuration Window
• Configuring an ATM Interface
• ATM Interface Configuration Window—Detailed Description
Note The ATM Interface Configuration dialog is not supported by the Cisco 10720 Series Router, as it does
not support the ATM interfaces.
Viewing the ATM Interface Configuration Window
To view the ATM Interface Configuration window, proceed as follows these steps:
Step 1 Right-click on a selected ATM interface, then choose Cisco 12000/10720 Manager>
Configuration>ATM>Configuration.
