12-7
Cisco 12000/10700 v3.1.1 Router Manager User Guide
OL-4455-01
Chapter 12 Managing ATM Connections
Creating ATM Connections
Creating ATM Connections
To create a PVC or SVC, proceed as follows:
1. Upload any existing ATM connections and QoS (Quality of Service) profiles, if available (for
details, see “Uploading Existing ATM Connections and QoS Profiles” section on page 12-7) or
2. Create an ATM QoS profile, when required (see “Managing ATM QoS Profiles” section on
page 12-12 for further details):
a. Deploy (create) the PVC or SVC in the CEMF, using the Deployment Wizard (for details, see
“Deploying a PVC Object” section on page 12-18 or “Deploying an SVC Object” section on
page 12-22). This process creates the PVC or SVC in Cisco EMF only; it does not create the
connection on the device.
b. Apply the QoS profile to the PVC or SVC (for details, see “Applying an ATM QoS Profile to an
ATM Connection” section on page 12-28).
c. Configure the fields for the PVC or SVC, including layer 2 information (for details, see “ATM
PVC Configuration” section on page 12-30 or the “SVC Configuration” section on page 12-37)
You can then create the connection on the device by commissioning the PVC or SVC for
management.
Uploading Existing ATM Connections and QoS Profiles
This section describes how to upload existing ATM connections and profiles (previously configured on
a Cisco device) into the Cisco 12000/10720 Router Manager application. Uploading saves time and
effort re-configuring ATM connections and profiles that already exist on the device.
When you upload PVCs, any corresponding ATM QoS profiles are also uploaded. PVCs are discovered
and placed into the normal state, so that management of these connections begins automatically. Once
these connections and/or profiles are uploaded, you can view and adjust them within Cisco 12000/10720
Router Manager. Existing ATM connections and QoS profiles are uploaded from the ATM Connection
Upload window.
Note The processes of uploading ATM connections and synchronizing the connections function in a similar
manner to upload the existing ATM connections and QoS profiles. So, any policy set for synchronization
(i.e. Normal, Device_is_Master, or CEMF_is_Master_after_first_sync) is applicable to Upload as well.
Refer ATM Connection Synchronization section for details on policy setting for ATM Connection
Synchronization.
Not Present N/A Present Remove it from device
Not Present N/A Not Present N/A
Table 12-5 CemfIsMasterAfterFirstSync Policy (continued)
VCL in Cisco EMF VCL State VCL on Device Behavior
