4-38
Cisco 12000/10700 v3.1.1 Router Manager User Guide
OL-4455-01
Chapter 4 Managing Chassis
RPR Configuration
Operations Done Locally
Add—Click Add to move the text string (displayed in the search criteria data entry box) into the criteria
name list. Then click Upload to commence your search.
Delete—Click Delete to remove any selected text string from the criteria name list.
Operations on Device
Upload—Click Upload to upload the running configuration file from the selected chassis and
automatically open the running configuration file in a vi editor (allowing you to edit the configuration
file).
Download—Click Download to download the edited running configuration file to the selected chassis.
RPR Configuration
Note This feature is not available with the Cisco 10720 Routers.
The RPR Configuration window allows you to configure the Redundancy Mode, Preferred route
processor and the perform switchover operation. The RPR Configuration section covers the following
areas:
• Viewing the RPR Configuration Window
• RPR Configuration Window—Detailed Description
Viewing the RPR Configuration Window
To view the RPR Configuration window, proceed as follows:
Step 1 Right click (on a relevant object icon in the Map Viewer window or from an object pick list) and select
Configuration>RPR Configuration option. See Table 4-1 on page 4-2 for information on which
objects allow you to launch the RPR Configuration window.
