8-27
Cisco 12000/10700 v3.1.1 Router Manager User Guide
OL-4455-01
Chapter 8 Interface Configuration
SRP Interface Side Configuration
Alarms Tab
The Alarms tab displays two areas: Reporting & Threshold, and Reporting
Reporting and Threshold
The Reporting & Threshold area allows you to configure the following information:
B1 BER Threshold Crossing Alarm—Allows you to enable/disable threshold limits for the system to
prompt appropriate B1 BER Threshold alarm messages.
B2 BER Threshold Crossing Alarm—Allows you to enable/disable threshold limits for the system to
prompt appropriate B2 BER Threshold alarm messages.
B3 BER Threshold Crossing Alarm—Allows you to enable/disable threshold limits for the system to
prompt appropriate B3 BER Threshold alarm messages.
Signal Degrade BER—Allows you to enable/disable threshold limits for the system to prompt
appropriate Signal Degrade BER Threshold alarm messages
Signal Fail BER—Allows you to enable/disable threshold limits for the system to prompt appropriate
Signal Fail BER Threshold alarm messages
B1 Threshold <3-9> (in 10e-)—Displays B1 BER threshold value in 10e-, between 3-9
B2 Threshold <3-9> (in 10e-)—Displays B2 BER threshold value in 10e-, between 3-9
B3 Threshold <3-9> (in 10e-)—Displays B3 BER threshold value in 10e-, between 3-9
SD Threshold <3-9> (in 10e-)—Displays Signal Degrade threshold value in 10e-, between 3-9
SF Threshold <3-9> (in 10e-)—Displays Signal Fail BER threshold value in 10e-, between 3-9
Reporting
Section Loss of Frame Errors—Allows you to enable/disable the loss of frame errors alarm messages.
Section Loss of Signal Errors—Allows you to enable/disable the loss of signal errors alarm messages.
Line Alarm Indication Signal Errors—Allows you to enable/disable the line alarm indication signal
errors alarm messages.
Line Remote Defect Indication Errors—Allows you to enable/disable the line remote defect indication
errors alarm messages.
Path Loss of Pointer Errors—Allows you to enable/disable the path loss of pointer errors alarm
messages.
Path Alarm Indication Signal Errors—Allows you to enable/disable the path alarm indication signal
errors alarm messages.
Path Remote Defect Indication Errors—Allows you to enable/disable the path remote defect indication
errors alarm messages.
