21-5
Cisco 12000/10700 v3.1.1 Router Manager User Guide
OL-4455-01
Chapter 21 Troubleshooting and FAQs
Configuration
You will see the following entries related to the Syslog configuration:
logging history size 10
logging history debugging
logging trap debugging
show logging history
This provides summary information on the logging facilities, the number of messages sent/dropped,
etc.
Syslog can be configured from the Cisco 12000/10720 Router Manager. Right click on the chassis
object and select the Fault > Syslog Messages option. You can configure the following Syslog
options:
–
Maximum Table Entries—Displays the upper limit on the number of entries that the area can
contain.
–
Minimum SysLog Severity—Any message with a severity less than this one will be ignored by
the agent. This field can be set to emergency, alert, critical, error, warning, notice, info, or
debug.
–
Notifications Enabled—Displays whether Syslog SNMP notifications are enabled or not
enabled.
BGP Configuration
Q.
The GSR is configured for BGP but the BGP Configuration GUI displays ERROR on most of the
settings. The GSRs
Decommissioned then commissioned GSRs again. Settings are seen on BGP Configuration GUI.
A.
Make sure you have IOS Login and Enable passwords configured in the EMS. Right click on the
chassis object and choose Configuration > Management Information. You configure the
passwords on the IOS/Command Line Security tab.
ATM Sub-Interface Configuration
Q.
Where do I find ATM sub-interface configuration? The ATM Interface Configuration GUI gives no
such information.
A.
VCLs, SVCs, and VLANs are only shown under the Component Managed View not the Physical
View. In order to invoke the ATM VCL Configuration window, go to the Component Managed
View, then right-click on a selected interface, then choose Cisco 12000/10720 Manager >
Configuration > ATM > VCL Configuration.
ATM IP Configuration GUI Display ERROR Settings
Q.
Though we have the ATM IP settings for an ATM port on the ATM IP Configuration GUI, it
displays ERROR for all settings.
A.
Make sure you have IOS Login and Enable passwords configured in the Cisco 12000/10720 Router
Manager. Right click on the chassis object and choose Configuration > Management
Information. Choose the IOS/Command Line Security tab.
