Chapter 12 Managing ATM Connections
Launching the ATM Connections Windows
Launching the ATM Connections Windows
Table 12-1 displays each object type that can be used to open the Cisco 12000/10720 Router Manager
windows that allow you to upload, create and configure ATM connections.
Note Table 12-1 lists the menu options to launch the ATM Connections dialogs from the site level.
For example, the ATM QoS Profiles Configuration window can be launched from a Site, Chassis,
Module and interface object.
ATM Connection Synchronization
The idea behind the ATM Connection Synchronization is to provide a mechanism to update the ATM
connection details stored in the Cisco EMF from the current configuration on a device. This is necessary
if the device is updated, for e.g., if a new ATM connection is added (or removed) then the Cisco EMF
should be able to re-read from the device and update the Cisco EMF by creating new objects if necessary.
The Synchronization process is initiated in the following circumstances:
• Every time the chassis is commissioned.
• When the chassis loses connectivity and again establishes connection with the device.
• Changes to device configuration made via SNMP requests from a source other than Cisco
12000/10720 Router Manager.
• Changes to device configuration made via IOS CLI requests from a source other than the one that
has the Cisco 12000/10720 Router Manager running.
Table 12-1 Launching the ATM Connection Windows
Cisco 12000/10720 Router
Manager Window/Task
Objects (that can be selected) to Open the
Window
Menu Options to Select to Open Window
Site Chassis
12000
Series
Chassis
10720
Module Interface
ATM Connection
Upload
Yes Yes No No No Cisco 12000/10720 Manager>Configuration>
Chassis>Upload ATM Connections
ATM QoS Profile
Configuration
Yes Yes No Yes Yes Cisco 12000/10720 Manager>Configuration>
Interface>QoS>ATM QoS Profile Configuration
ATM QoS Profile
Management
Yes Yes No Yes Yes Cisco 12000/10720 Manager>Configuration>
Interface>QoS>ATM QoS Profile Management
ATM SVC
Configuration
Yes Yes No Yes Yes Cisco 12000/10720 Manager>Configuration>
Interface>ATM>SVC Configuration
ATM VCL
Configuration
Yes Yes No Yes Yes Cisco 12000/10720 Manager>Configuration>
Interface>ATM>VCL Configuration
ATM VCL Status Yes Yes No Yes Yes Cisco 12000/10720 Manager>Fault>Interface>
ATM>Connection Status
