CHAPTER
6-1
Cisco 12000/10700 v3.1.1 Router Manager User Guide
OL-4455-01
6
Managing Interfaces
This chapter describes the management tasks that can be performed on the interfaces of the Cisco 12000
Series and the Cisco 10720 Router being managed using the Cisco 12000/10720 Router Manager
application. A number of interface topics (and the order in which they should be carried out) are
identified in Figure 6-1.
Figure 6-1 Managing Interfaces
Cisco 12000/10720 Router Manager Interface Naming
Conventions
The interfaces under each linecard are named according to the names displayed by the IOS in the router,
for example, interfaces under an ATM Linecard in slot 1 are named as: ATM 1-0, ATM 1-1, ATM 1-2,
ATM 1-3 and interfaces on a POS Linecard in slot 3 are named as POS 3-0, POS 3-1 and so on.
Table 6-1 lists abbreviated interface names for other linecards in Cisco 12000/10720 Router Manager.
Interface
profiles
Interface
configuration
Interface
performance
Interface
status
Layer 3 QoS
ATM
connections
Interface
fault
VLAN
sub-interfaces
Create and apply new interface profiles or connections
Configure interfaces manually or through profiles.
Commission/decommission interfaces and start/stop performance
polling on interfaces.
75637
Monitor interface
performance
Monitor interface
status
Create and apply
WRED or CAR
QoS profiles on
an interface
Upload existing ATM
connections or create
PVCs and SVCs
Monitor faults on
interfaces
Upload existing VLAN
sub-interface or create
VLAN sub-interfaces
