8-26
Cisco 12000/10700 v3.1.1 Router Manager User Guide
OL-4455-01
Chapter 8 Interface Configuration
SRP Interface Side Configuration
SRP Interface Side Configuration Window—Detailed Description
The SRP Interface Side Configuration window has two tabs namely: General, and Alarms
General Tab
The General tab displays three areas: General, SONET Overhead and IPS SONET.
General
The General area allows you to configure the following information:
Clock Source—Allows you to configure the clock source from available options. This can either be
internal (within the device) or Line (the network clock).
Loopback—Allows you to configure the loopback mode. It indicates the loopback mode for the SRP
Side. The available options are: Disabled, Internal or Line
Framing—Allows you to configure SDH or SONET type framing. It indicates the framing mode of the
side.
IPS Management Request Mode—Allows you to configure the IPS management request mode for the
side. The available options are: noRequest, forced-switch, manual-switch, waitToRestore,
signalDegrade, and signalFail.
Note The waitToRestore, signalDegrade and SignalFail modes cannot be set for the Interface, however the
user can view the values as they are read-only values.
SONET Overhead
Path Signal Identifier—Allow you to configure the path signal identifier. The permissible values range
from 0 to 255.
Section Trace Byte—Allows you to configure the section trace byte. The permissible values are 0 to 255.
Note If the device has pre-defined default values for the Path Signal Identifier and Section Trace Byte
parameters, the same values are displayed in this area when the window is opened.
IPS SONET
Protected—Allows you to configure the Protected mode. The available options are: enable and disable
SD Threshold <3-9> (in 10e-)—Allows you to select the Signal Degrade threshold value in 10e-,
between 3-9
SF Threshold <3-9> (in 10e-)—Allows you to select the Signal Fail BER threshold value in 10e-,
between 3-9
