Cisco 12000/10700 v3.1.1 Router Manager User Guide
OL-4455-01
Chapter 7 Interface Profiles
Interface Profile Types
This chapter contains the following information:
• “Interface Profile Types” section on page 7-2
• “Launching the Interface Profile Windows” section on page 7-2
• “Creating an ATM Interface Profile” section on page 7-3
• “Creating a POS Interface Profile” section on page 7-12
• “Creating an HSRP Profile” section on page 7-9
• “Creating a SRP Side Profile” section on page 7-17
Interface Profile Types
Table 7-1 outlines the profile types available, and details the windows that apply to each profile type.
Launching the Interface Profile Windows
Table 7-2 displays the Interface Profile windows that can be launched from each object type. For
example, the POS Interface Profile window can be launched from a Site, Chassis, Module or a POS
Interface.
Note Table 7-2 lists the menu options to launch the interface profile dialogs from the site level.
Table 7-1 Interface Profile Types and Applicable Cisco 12000/10720 Router Manager Windows
Interface Profile Type Applicable Windows
ATM Profile ATM Configuration
HSRP Profile Ethernet Configuration
POS Profile POS Configuration
SRP Side Profile SRP Side Configuration
Table 7-2 Launching the Interface Profile Windows
Cisco 12000/10720
Router Manager
Window/Task
Objects (that can be selected) to Open the Window Menu Options to Select to Open Window
Site Chassis
12000
Series
Chassis
10720
Module Interface
Creating an ATM
Interface Profile
Yes Yes No Yes Generic,
ATM
Cisco 12000/10720 Manager>Configuration>
Interface>ATM> Configuration Profile
Creating an HSRP
Profile
Yes Yes Yes Yes Generic,
Ethernet
Cisco 12000/10720 Manager>Configuration>
Interface> IP>HSRP Configuration Profile
Creating a POS
Interface Profile
Yes Yes Yes Yes Generic,
POS
Cisco 12000/10720 Manager>Configuration>
Interface> POS>Configuration Profile
Creating a SRP Side
Profile
Yes Yes Yes Yes Generic,
SRP
Cisco 12000/10720 Manager>Configuration>
Interface>SRP> Side>Configuration Profile
