14-36
Cisco 12000/10700 v3.1.1 Router Manager User Guide
OL-4455-01
Chapter 14 Routing
BGP Address Family Configuration
AF-Neighbor Tab—Detailed Description
The AF-Neighbor tab displays a single area: Neighbor Information.
Neighbor Information
Neighbor IP Address—Specifies the IP address of the neighbor router for the address family.
Remote AS—Specifies the neighbor routers autonomous system number. This value can range from1 to
65535.
Activate—Enables the neighbor to exchange prefixes for the specified family type with the local router.
Neighbor Send Community—Specifies the community attribute sent in the route updates to a peer. The
default is not to send community attribute in route updates.
Action
Add/Remove AF Neighbor—Clicking on the Add/Remove AF Neighbor button opens the BGP Address
Family - Neighbor Configuration window.
BGP Address Family—Neighbor Configuration
The BGP Address Family - Neighbor Configuration window allows the user to add or remove neighbor
configurations for BGP address families. To configure a Neighbor for an address family, proceed as
follows:
Step 1 Open the BGP Address-Family Configuration window. See “Viewing the AF-General Tab on the BGP
Address-Family Configuration Window” section on page 14-27 for further details. Click on the
AF—Neighbor Tab.
Step 2 Choose a chassis and the address family from the left side of the window.
Note You can choose multiple chassis and address families (from the list provided at the left side of
the window) which allows you to launch the BGP Address Family - Neighbor Configuration
window for the selected chassis.
Step 3 Click on the Add/Remove AF Neighbor button to open the BGP Address Family - Neighbor
Configuration window.
