10-33
Cisco 12000/10700 v3.1.1 Router Manager User Guide
OL-4455-01
Chapter 10 Interface Performance
SRP Side Performance
Octets Out
Low Priority Unicast—Displays the number of low priority unicast octets going to the higher layer.
High Priority Unicast—Displays the number of high priority unicast octets going to the higher layer.
Low Priority Multicast—Displays the number of low priority multicast octets going to the higher layer.
High Priority Multicast—Displays the number of high priority multicast octets going to the higher layer.
Errors Tab
The Errors tab displays two areas: Ring and Host
Ring
Received TTL Expiry Packets—Displays the number of discarded packets received from the physical
layer, due to TTL expiry
Received Aborted Packets—Displays the number of packets aborted from the physical layer by an abort
sequence code.
Received Giant Packets—Displays the number of giant packets received from the physical layer.
Note A giant packet is larger than the maximum size packet, which is 9216 octets
Received Short Packets—Displays the number of short packets received from the physical layer.
Note A short packet is 16 octets or less
CRC Error Packets—Displays the number of packets with CRC errors.
Host
Received Discarded Packets—Displays the number of packets that are not delivered to a higher layer due
to lack of resources.
Received Giant Packets—Displays the number of packets discarded due to packet size being too big for
the higher layer.
Received Short Packets—Displays the number of packets discarded due to packet size being too small
for the higher layer.
