Using the Data Watch Window
372 SPU 780 01EMAN May 2002 177
Data Watch Window Overview
Overview The watch window is the primary Data Watch Window. You can select any valid
address for the current device and view the data for that address. Up to 100
addresses of any type may be entered and tracked. The data may be edited at any
time. Register values may be changed and discrete values may be enabled or
forced on or off. Addresses are automatically saved on exit and reloaded on entry.
Any register data may be viewed or edited with any selected radix type. Available
radices are Decimal, Hex, Binary, ASCII, Signed integer, BCD, 32-bit Floating point
or 32-bit integer. The bottom status bar will display various information including
Status messages, Offline/Online/Emulation state, Running/Stopped state, Trigger
info and Clamping info.
Adding
Addresses to
Track in the Data
Watch Window
In the data watch window:
Clearing
Addresses
From the right-click menu:
Loading
Addresses and
Data from a Log
File
From the right-click menu:
Step Action Result
1 Double-click or press ENTER in the first available Address cell.
2 Insert a valid address into the Address cell.
3 Press ENTER to insert the address,
ESC to cancel the entry.
The Data and Radix fields are
automatically populated if the address
exists in the project. You can edit the
data or radix of an address by double-
clicking on the cell you want to change.
Step Action Result
1Select Clear. All addresses are cleared from the
Window.
Step Action Result
1Select Load. The DataWatch Address Load dialog
appears.
2 Select a log file and click OK. All addresses from the file are added to
the Data Watch Window.
