3. Setup
3 - 27
High-gain specifications
No. Abbrev. Parameter name Explanation
F E D C B A 9 8 7 6 5 4 3 2 1 0
pen ent mtyp
bit Explanation
0 Set the motor type. Set this along with SV017 (SPEC)/spm.
1 [1] When SV017/spm=0 (Normal drive unit)
2 Setting 0x 1x 2x 3x 4x 5x 6x 7x
3 x0 HA40N HA50L HA53L
4
mtyp
x1 HA80N HA100L HA103L
5 x2 HA100N HA200L HA203L
6 x3 HA200N HA300L HA303L
7 x4 HA300N HA500L HA503L
x5 HA700N
x6 HA900N
x7 HALH11K2
x8 HALH15K2
x9
xA HA150L HA153L
xB
xC
xD
xE HALF11K2
xF HA-LF15K2
Setting 8x 9x Ax Bx Cx Dx Ex Fx
x0 HA43N HC52 HC53
x1 HA83N HC102 HC103 HC103R
x2 HA103N HC152 HC153 HC153R
x3 HA203N HC202 HC203 HC203R
x4 HA303N HC352 HC353 HC353R
x5 HA703N HC452 HC453 HC503R
x6 HC702 HC703
x7 HC902
x8
x9
xA HA93N
xB
xC HA053N
xD HA13N
xE HA23N
xF HA33N
[2] When SV017/spm=1 (S type drive unit)
Setting 8x 9x Ax Bx Cx Dx Ex Fx
x0
x1
x2
x3
x4 HC353
x5 HC452 HC453
x6 HC702 HC703
x7 HC902
x8
x9
xA
xB
xC
xD
xE
xF
SV025 MTYP*
Motor/Detector
type
Parameters with an asterisk * in the abbreviation, such as PC1*, are validated with the NC power turned ON again.
